  Zacns 88 tank wagon

The four-axle 88 m³ tank wagon is designed to transport hazardous substances in a liquid state according to the RID regulation.

The wagon complies with the European legislation TSI WAG, GCU and UIC.

  • Length over buffers

  • Tare weight

    • Loading weight

    • Total weight

    • Tank code under RID

  • 15,000 mm

  • 20,8 t ± 2%

    • 69.2 t

    • 90 t

    • L4BH

  • Maximum axle load

  • Bogie

    • Brake

    • Distance between pivots

      • Kinematic gauge

      • Tank slope

        • Loading capacity

        • No. of wagons in a train (700 m)

  • 22.5 t

  • Y25 Lsd

    • GP

    • 9,960 mm

      • G1 - EN 15273-2

      • 1°

        • 88 m³

        • 45


Universal

High transport efficiency

GPS locator

Unique parameters
tv_p_88
p_88m3 1b

  Zacns 98 tank wagon

The four-axle 98 m³ tank wagon is designed to transport hazardous substances in a liquid state according to the RID regulation.

The wagon complies with the European legislation TSI WAG, GCU and UIC.

  • Length over buffers

  • Tare weight

    • Loading weight

    • Total weight

    • Tank code under RID

  • 16,400 mm

  • 21,5 t ± 2%

    • 68.5 t

    • 90 t

    • L4BH

  • Maximum axle load

  • Bogie

    • Brake

    • Distance between pivots

      • Kinematic gauge

      • Tank slope

        • Loading capacity

        • No. of wagons in a train (700 m)

  • 22.5 t

  • Y25 Lsd

    • GP

    • 11,360 mm

      • G1 - EN 15273-2

      • 1°

        • 98 m³

        • 41


Safe

High transport efficiency

GPS locator

Unique parameters
tv_p_88
p_88m3 1b

  Zacens 78 tank wagon

The four-axle 78 m³ tank wagon is designed to transport heavy oil products.

The wagon complies with the European legislation TSI WAG, GCU and UIC.

  • Length over buffers

  • Tare weight

    • Loading weight

    • Total weight

    • Tank code under RID

    • Heating circuit

    • Environmental temperature

    • Heat insulation

  • 15,940 mm

  • 24 t ± 2%

    • 66 t

    • 90 t

    • L4BH

    • 8 m²

    • 190 °C

    • 100 mm

  • Maximum axle load

  • Bogie

    • Brake

    • Distance between pivots

      • Kinematic gauge

      • Tank slope

        • Loading capacity

        • No. of wagons in a train (700 m)

  • 22.5 t

  • Y25 Lsd

    • GP

    • 10,900 mm

      • G1 - EN 15273-2

      • 1°

        • 78 m³

        • 42


Heat insulated

High transport efficiency

GPS locator

Unique parameters
tv_p_88
p_88m3 1b

  Sggrss 80' platform wagon

The six-axle platform wagon is designed to transport 20´, 30´and 40´size containers according to the UIC 592-2 regulation and swap bodies with destination code C according to 596-6.

The wagon complies with the European legislation TSI WAG, GCU and UIC.

  • Length over buffers

  • Tare weight

    • Loading weight

    • Total weight

  • 26,390 mm

  • 26.5 t ± 2%

    • 108.5 t

    • 135 t

  • Maximum axle load

  • Bogie

    • Brake

    • Distance between pivots

      • Kinematic gauge

      • Loading length

        • Loading height

        • No. of wagons in a train (700 m)

  • 22.5 t

  • Y25 Ls1-K

    • GP-A

    • 2 x 10 425 mm

      • G1 - EN 15273-2

      • 2 x 12 220 mm

        • 1,155 mm

        • 26


Effective space

Light construction

GPS locator

Universal
tv_p_88
p_88m3 1b

  Sggmrss 90' platform wagon

The six-axle platform wagon is designed to transport 20´, 30´and 40´size containers and swap bodies of various sizes – 6.05 – 8.15 m, 9.125 – 9.3 m, 12.192 m, 13.6 m.

The wagon complies with the European legislation TSI WAG, GCU and UIC.

  • Length over buffers

  • Tare weight

    • Loading weight

    • Total weight

  • 29 590 mm

  • 27,9 t ± 2%

    • 107,1 t

    • 135 t

  • Maximum axle load

  • Bogie

    • Brake

    • Distance between pivots

      • Kinematic gauge

      • Loading length

        • Loading height

        • No. of wagons in a train (700 m)

  • 22,5 t

  • Y25 Ls1-K

    • GP-A

    • 2 x 12 025 mm

      • G1 - EN 15273-2

      • 2 x 13 820 mm

        • 1 155 mm

        • 23


Effective space

Light construction

GPS locator

Universal
tv_p_88
p_88m3 1b

  Y25 Ls(s)d1 bogie

The two-axle bogie of a standard construction is intended for railway freight wagons and is designed to satisfy all requirements of railway freight transport.

The bogie complies with the European legislation TSI WAG, GCU and UIC.

  • Track gauge

  • Bogie wheelbase

    • Weight

  • 1,435 mm

  • 1,800 mm

    • 4.5 t

  • Maximum axle load

  • Maximum speed

    • Brake

  • 22.5 t

  • 120 km/h

    • 2 x BGU


Safe

Light construction

Simple maintenance

Universal
tv_p_88
p_88m3 1b

  Y25 Ls1 bogie

The two-axle bogie of a standard construction is intended for railway freight wagons and is designed to satisfy all requirements of railway freight transport.

The bogie complies with the European legislation TSI WAG, GCU and UIC.

  • Track gauge

  • Bogie wheelbase

    • Weight

  • 1,435 mm

  • 1,800 mm

    • 4.4 t

  • Maximum axle load

  • Maximum speed

    • Brake

  • 22.5 t

  • 120 km/h

    • 2 x BG


Safe

Light construction

Simple maintenance

Universal
tv_p_88
p_88m3 1b

  Y25 Lsd bogie

The two-axle bogie with an H-shaped frame is designed for railway freight wagons to satisfy all requirements of railway freight transport.

The bogie complies with the European legislation TSI WAG, GCU and UIC.

  • Track gauge

  • Bogie wheelbase

    • Weight

  • 1,435 mm

  • 1,800 mm

    • 4.1 t

  • Maximum axle load

  • Maximum speed

    • Brake

  • 22.5 t

  • 120 km/h

    • 1 x BGU


Safe

Light construction

Simple maintenance

Universal
tv_p_88
p_88m3 1b

  Y25 Lsi(f) bogie

The two-axle bogie with an H-shaped frame and an integrated brake is designed for railway freight wagons to satisfy all requirements of railway freight transport.

The bogie complies with the European legislation TSI WAG, GCU and UIC.

  • Track gauge

  • Bogie wheelbase

    • Weight

  • 1,435 mm

  • 1,800 mm

    • 4.1 t

  • Maximum axle load

  • Maximum speed

    • Brake

  • 22.5 t

  • 120 km/h

    • Knorr, Wabtec


Safe

Light construction

Simple maintenance

Universal
